The ability to host and run reports in Web AppBuilder apps is provided by custom widgets that were developed by VertiGIS Studio for this purpose.

There are two widgets:

▪2D Widget: The 2D widget runs reports in 2D apps.

▪3D Widget: The 3D widget runs reports in 3D apps.

If you want to use Web AppBuilder apps to host reports, you must first register the widgets. You only need to register the widgets one time, and then you can use them in as many apps as you want.

VertiGIS Studio Reporting supports three editions of Web AppBuilder. Which edition you use depends on whether you use on-premises Reporting or cloud Reporting:

▪On-Premises Reporting: You can use either supported edition of Web AppBuilder:

•Web AppBuilder in Portal for ArcGIS: If you use on-premises VertiGIS Studio Reporting with Portal for ArcGIS, you can use the edition of Web AppBuilder that comes with Portal for ArcGIS.

•Web AppBuilder (Developer Edition): You can use the Developer Edition of Web AppBuilder with on-premises VertiGIS Studio Reporting.

▪Cloud Reporting: You can use Web AppBuilder (Developer Edition) or Web AppBuilder for ArcGIS Online with cloud Reporting.

Follow the instructions for the edition of Web AppBuilder you use:

▪Register the Widgets with Web AppBuilder in Portal for ArcGIS

▪Register the Widget with Web AppBuilder in ArcGIS Online

▪Deploy the Widgets to Web AppBuilder (Developer Edition)
